Information display, engine
Regarding: L60F, L70F, L90F
Under menu Engine in the information display unit, it is possible
to read status according to the following menu figures.
Temperature and pressure are shown as bars. The functions
have either display of normal-low or normal-high.
- Half bar is shown for normal value.
- In case of low value, bar with marking Low is shown.
- In case of high value, bar with marking High is shown.
By selecting Service mode, number values can be shown instead
of bars. Conditions for activation of Service mode, see
Information
display, general page 38
.
To return to previous figure, press [ESC].
Air filter
xxxx = Normal / Clogged
In case of clogged air filter, alarm “ CheckClogged air filter engine”
is also generated.
Engine
Coolant temperature
High
Oil pressure
Low
Air filter
xxxx
Oil temperature
High
Engine rpm
xxxx rpm
Fan rpm
xxxx rpm
43
