Information display, axles / brakes
Regarding: L60F, L70F, L90F
Under menu Axles/Brakes in the information display unit, it is
possible to read status according to the following menu figures.
Pressure and temperature are shown as bars. The functions have
either display of normal-low or normal-high.
- Half bar is shown for normal value.
- In case of low value, bar with marking Low is shown.
- In case of high value, bar with marking High is shown.
By selecting Service mode, number values can be obtained for
temperature and pressure. Conditions for activation of Service
mode, see
Information display, general page 38
.
To return to previous figure, press [ESC].
Axles / Brakes
Brake pressure
Low
Oil temp. Front axle
High
Oil temp. Rear axle
High
47
