Information display, service mode
Regarding: L60F, L70F, L90F
Under the menu Service ( Service mode) in the information panel,
there are the following information and tests.
Select menu with arrow key, press SELECT.
Conditions for activating Service mode, see
Information display,
general page 38
.
To return to previous figure, press [ESC].
Next service
Resid. time: Time to next service.
Interval: Shows selected service interval.
Confirm: Press SELECT to confirm performed service.
Central lubrication
Interval: Shows selected interval ( Light / Normal / Heavy).
To change setting, press SELECT. Make selection with the arrow
keys and press SELECT to confirm the selection.
Level: Shows lubricant level in the reservoir. ( Normal / Low).
Test
Make test selection with the arrow keys.
Bulb test: Press SELECT and all control lights on the instrument
panel should be lit.
Brake test: Press SELECT.
1 Accelerate over 20 km/h
2 Brake to standstill
3 Read off the test result: Retardation and Pressure.
To return to previous figure, press ESC.
Brake test log: Press SELECT.
Memory of retardation for the last 3 brake applications.
Memory of output brake pressure for the last 3 brake applications.
To return to previous figure, press ESC.
Sound test: Press SELECT. Off changes to On and obtains a
cooling fan speed that is 70% max. engine rpm.
To cancel the test, press SELECT.
Service ( Service mode)
Next service
Central lubrication
Test
I/O-List
Next service
Resid. time 125 h
Interval 250 h
Confirm service No
Central lubrication
Interval Normal
Level Normal
Test
Bulb test Off
Brake test Off
Brake test log Off
Sound test Off
Pressure test fan
pump
Off
Brake test
Retardation
x m/s
2
Pressure xx bar
close:
ESC
Brake test log
Log1:
xx bar xx m/s
2
Log2:
xx bar xx m/s
2
Log3:
xx bar xx m/s
2
close:
ESC
53
