26
WWW.VORONDESIGN.COM
THREAD SCREWS INTO PLASTIC, BE GENTLE
Note that OPB991P or OPB991L wired sensors
will only have one M3x8 here, while the wired
OPB991T and all PCB-based sensors have two
screws.
POINTS FOR NEATNESS
Voron takes wiring seriously, and you should too.
Use a zip-tie to secure wires to the upper . On the
Wired sensor option, use the printed channel to
tuck the wires away safely from moving parts.
(1 or 2) M3x8 SHCS
