Restoring nominal values
If necessary, the nominal factory-set values for V1 and V2 can be restored using the following procedure:
Operation
Depending on the mode selected during installation:
-two-speed mode: the appliance operates continuously; two speeds V1 and V2 can be selected using an
external switch
-adjustable speed mode: the appliance can operate at a speed which is adjusted between Vmin and Vmax
(via an external potentiometer). The VORTICE ON/OFF control box + potentiometer (code 12826 / 12828, on
request) can also be used.
Maintenance and cleaning
Fig. 26 ÷ 28.
Technical specification
Cut off the power supply
Set the dip-switch SW2 indicated in the figure: Int.3=ON
ON
1 2 3 4
OFF
Restore the power supply:
V1 and V2 are automatically restored to the nominal factory-
set values corresponding to the selected model, as described above.
The restoring of nominal values is indicated by two quick flashes of an
LED on the card. The motor is deactivated automatically
Cut off the power supply
Reset the dip-switch SW2 indicated in the figure: Int.3=OFF
ON
1 2 3 4
OFF
15
ENGLISH
PRODUCT V Hz
Power
(10V/ 8V/
6V /4V)
[W]
Airflow
(10V/ 8V/
6V /4V)
[m
3
/h]
Pressure
(10V/ 8V/
6V /4V)
[mmH
2
O]
RPM
(10V/ 8V/
6V /4V)
Sound
pressure level
[LpA [db(A)] 3m
-IRRADIATED-
(10V/ 8V/ 6V /4V)
INSULATION CLASS
Max room
temperature [°C]
LINEO 250 ES 220-240 50-60
126 / 75
35 / 20
1475 / 1235
935 / 755
40,4 / 28,9
16,9 / 11
2690 / 2250
1720 / 1390
44 / 39,9 /
33,1 / 28,4
II 50
LINEO 315 ES 220-240 50-60
230 / 170
77 / 45
2625 / 2320
1740 / 1415
43 / 38,6
21,9 / 14,6
2370 / 2130
1600 / 1300
47,5 / 44,8
44 / 42,5
II 50

Vortice LINEO 100 V0 ES Specifications
