8. Technical data
Name C-type/T-type foot Pareto
The height depends on the
choice of variant: from 65 to 125 cm
Maximum lifting load at 75 kg (full surface area)
Operating time 2 minutes “ON” and
18 minutes “OFF”
Safety shut-o
Ambient temperature must not be below +0°C
for operation and must not exceed + 35 °C
Sound emissions < 50 dB(A)
Travel speed 38 ± 2 mm/sek
Relative humidity 5 bis 85 %
Power supply 100 - 240 V
Current consumption max. 1,6 A
Protection type, IP class IPX0
Protection class II
Frequency range 50/60 Hz
Standby power, primary (typical) 0.1 W
