WABCO ABS/EBS CODE READER User Manual

20
Fault codes and their meaning
EN
SPN Aff ected component
10 Solenoid valve B
11 Internal outlet solenoid valve
211 GenericIO D1
212 GenericIO D2
213 GenericIO logic
214 GenericIO D4
215 GenericIO D5
216 GenericIO A1
217 GenericIO logic
218 GenericIO logic
251 Power supply
253 Memory calibration EEPROM
254 Control unit
VCSII
FMI Fault description
0 Value too high (short circuit to supply voltage)
1 Value too low (undervoltage / short circuit to ground / air gap)
2 Incorrect value (cable break)
3 Overvoltage or short circuit to supply voltage
4 Undervoltage or short circuit to ground
5 Current too low (cable break)
6 Current too high (interturn short circuit)
7 Mechanical fault (pole wheel defective)
8 Unusual frequency (impermissible wheel slip)
9 Unusual signal form (no wheel speed)
10 Unusual signal changes (speed jump)
11 Fault cannot be identifi ed
12 Internal electronic fault
13 Characteristic curve error (pole wheel eccentric)
14 Special fault / see fault note
15 Reserved (ECU defective)
TEBS-D
SPN Aff ected component
1 Rotational speed sensor c
2 Rotational speed sensor d
3 Rotational speed sensor e
4 Rotational speed sensor f
