Maintenance
Maintenance work 10.3
37
[en-US] | 10/2022 | 5100056183 | BH | Operator’s Manual
1. Remove dirt.
2. Open filler cap 1 slowly.
ð This allows any overpressure to escape.
3. Top up with fuel using a clean funnel up to the lower edge of the
filler neck.
ð Fuel specification see Technical Data on page 45
ð Fuel mixing chart see Technical Data on page 45
4. Close filler cap tightly.
10.3.3 Emptying the fuel system
1. Remove dirt.
2. Open filler cap.
3. Pump fuel into a suitable container or tank, e.g. with a suction lift
pump.
4. Close filler cap tightly.
5. Start the engine and let it run at idle until the fuel in the carburetor is
used up and the engine stops.
10.3.4 Cleaning and checking the air filter
NOTICE
Note on air filter cleaning!
The air filter insert can be damaged when knocked out.
► Carefully knock out the air filter element.
Remove air filter insert
1. Remove dirt in the area of the air filter cover 1.
10
