Wacker Neuson BS 50-4 Repair Manual

wc_br0114549en_11TOC.fm 5
Table of ContentsRammer Repair
Foreword 3
1 Safety Information 9
1.1 Signal Words Used in this Manual ....................................................... 9
1.2 Machine Description and Intended Use ............................................. 10
1.3 Safety Guidelines for Operating the Machine ..................................... 11
1.4 Operator Safety while Using Internal Combustion Engines ............... 13
1.5 Service Safety .................................................................................... 14
1.6 Service and Repair Safety .................................................................. 16
2Tools 17
2.1 Recommended Special Tools ............................................................ 17
2.2 Recommended Repair Tools .............................................................. 17
3 Maintenance Schedules 19
3.1 Periodic Maintenance Schedule (BS 50/60/70-2, BS 65) ................... 19
3.2 Periodic Maintenance Schedule (BS 500/600/700/650) ..................... 20
3.3 Periodic Maintenance Schedule (BS 50/60/70-2i) .............................. 21
3.4 Periodic Maintenance Schedule (BS 500/600/700-oi) ........................ 22
3.5 Periodic Maintenance Schedule (DS 70) ........................................... 23
3.6 Periodic Maintenance Schedule (DS 720) ......................................... 25
4 Engine and Upper Machine Components 27
4.1 Removing the Silencing Cover ........................................................... 27
4.2 Replacing the Throttle Control (2-stroke models, 2010 and later) ...... 28
4.3 Replacing the Throttle Control (2010 4-stroke models) ...................... 30
4.4 Throttle Control (pre-2010 models) .................................................... 33
4.5 Replacing the Stop Switch (2-stroke models, 2010 and later) ........... 34
4.6 Replacing the Stop Switch (4-stroke models, 2010 and later) ........... 37
4.7 Replacing the Guide Handle (2-stroke models, 2010 and later) ........ 39
4.8 Replacing the Guide Handle (4-stroke models, 2010 and later) ........ 42
4.9 Replacing the Guide Handle (pre-2010 models) ................................ 46

Wacker Neuson BS 50-4 Specifications

General

Engine Manufacturer	Honda
Stroke Height	65 mm
Fuel Type	Gasoline
Centrifugal Force	15 kN
Sound Pressure Level	92 dB(A)
Sound Power Level	105 dB(A)
Height	965 mm
Ramming Shoe Size	280 mm
Tank Capacity	3.1 l
Fuel Tank Capacity	3.1 l
Engine Type	4-cycle, single-cylinder, air-cooled
Percussion Rate	680 blows/min
