Wacker Neuson DINGO K9-4 - Page 31

Main Control Bank Assemblies Part Numbers &
Descriptions
Item Qty Part No. Description Notes
1 1 SEE NOTES MAIN CONTROL BANK UPGRADE TO 9330003103 REQUIRED
4
9330003026
SPOOL CONTROL CAP
CONTAINS 9330006025 x 1
4
9330006025
BOOT RUBBER CONTROL CAP
4
9330006001
BRASS INSERT SUITS SD5
CONTAINS 9330006010x 1 & 9330006011x
1
4
9330006010
O-RING BRASS INSERT INNER
4
9330006011
O-RING BRASS INSERT OUTER
4
9330006018
O-RING SUIT SD4/5/6
2
9330003027
SPOOL DRIVE SUIT SD5
2
9330003028
SPOOL LIFT/CROWD SUIT SD5
4
9330003029
SPRING RETURN KIT
1
9330003090
RELIEF VALVE
1
9330006022
SEAL KIT SUIT SD5 CONTROL BANK
1
9330003103
VALVE BANK MAIN CONTROL WITH DRAIN
UPGRADE REQUIRES : 9518000068x 1,
9518000069x 1, 9319000200x 1 & HOSE.
4
9330003026
SPOOL CONTROL CAP
CONTAINS 9330006025x 1
4
9330006025
BOOT RUBBER CONTROL CAP
4
9330006001
BRASS INSERT SUITS SD5
CONTAINS 9330006010 x 1 & 9330006011x
1
4
9330006010
O-RING BRASS INSERT INNER
4
9330006011
O-RING BRASS INSERT OUTER
4
9330006018
O-RING SUIT SD4/5/6
2
9330003027
SPOOL DRIVE SUIT SD5
2
9330003028
SPOOL LIFT/CROWD SUIT SD5
4
9330003029
SPRING RETURN KIT
1
9330003098
BLOCK SD5 DRAIN
4
9330006063
O-RING SD5 DRAIN BLOCK - EARLY
1
9330003127
O-RING SD5 DRAIN BLOCK - LATE
1
9330003090
RELIEF VALVE
1
9330006022
SEAL KIT SUIT SD5 CONTROL BANK
2 1
9001194485
SHORT HANDLE - LIFT
2 1
9001194486
SHORT HANDLE – CROWD / TILT
3 2
9330003031
LONG HANDLE - DRIVE
4 4
9316375503
NIPPLE M/M 3/8" BSPP x 9/16" JIC
9316375502 has been superceded
REPLACEMENT SEAL = 9330006042
5 4
9316377502
NIPPLE M/M 3/8" BSPP x 7/8" JIC ENC/SEAL
9316377501 has been superceded
REPLACEMENT SEAL = 9330006042
6 1
9312470000
BLANKING PLUG 3/8” BSPP
7 1
9312370000
BLANKING PLUG 1/2” BSPP
8 4
9121131000
HEX NUT M8
9 3
9111311060
HEX BOLT M8 x 60mm
10 5
9122131000
NYLOC NUT M8
11 2
9001194435
SPACER 30mm
12 1
9330003035
PUMP SELECTOR
1
9330003026
SPOOL CONTROL CAP
CONTAINS 9330006025 x1
1
9330006025
BOOT RUBBER CONTROL CAP
1
9330003063
SPOOL PUMP (HI/LOW) SELECTOR VALVE
2
9330006018
O-RING SUIT SD4/5/6
1
9330003001
DETENT KIT 2 POSITION
13 1
9330003052
FLOW CONTROL VALVE
1
9330006050
SEAL KIT FLOW CONTROL
1
9001194498
FLOW DIVIDER SEAL SEATING TOOL KIT
CONTAINS 1 x SHORT & 1 x LONG
14 1 OBSOLETE IMMOBILISER ASSEMBLY
Was 9001194033
DINGO K94 - SERIES I, II, III Revision 1.3 September 2020
Page 31
