Wacker Neuson DINGO K9-4 - Page 32

Item Qty Part No. Description Notes
15 1
9314374801
NIPPLE M/M 3/8" BSPP x 7/8" JIC ENC/SEAL
REPLACEMENT SEAL =
9330006042
16 2
9111311085
HEX BOLT M8 x 85mm
17 1
9315337371
ELBOW M/M 3/8" BSPP x 3/8" BSPP 2 NUTS
9315337370
has been superceded
REPLACEMENT O-RING =
9330006016
x 2
18 1
9331203002
IN-LINE CHECK VALVE
19 2
9316374700
NIPPLE ADJUSTABLE M/M 3/8" x 1/2" BSPP
REPLACEMENT SEAL =
9330006042
20 1
9001194414
PIPE – PUMP SELECTOR TO REMOTE BANK (AP)
21 2
9315477501
ELBOW M/M 1/2” BSPP x 7/8” JIC
REPLACEMENT O-RING =
9330006015
22 1
9001194413
PIPE – MAIN BANK TO DUMP (CD)
23 1 9317769575 TEE F/M/M 7/8" JIC x 1 1/16" JIC x 7/8" JIC
24 1
9316476502
NIPPLE M/M 1/2" BSPP x 3/4" JIC ENC/SEAL
9316476501
has been superceded
REPLACEMENT SEAL =
9330006043
25 1
9330003018
FLOW CONTROL HANDLE
26 1
9001194427
PIPE – REMOTE BANK TO AUX (A3)
27 1
9001194428
PIPE – REMOTE BANK TO SMALL AUX (A4)
28 1
9001194426
PIPE – REMOTE BANK TO AUX (A2)
29 1
9001194425
PIPE – REMOTE BANK TO LARGE AUX (A1)
30 1
9001194429
PIPE – MAIN BANK TO CROWD RAM SHORT
HOSE (T1)
31 1
9001194430
PIPE – MAIN BANK TO CROWD RAM LONG
HOSE (T2)
32 4
9316555500
NIPPLE M/M 9/16" JIC x 9/16" JIC BULKHEAD
33 1
9001194481
REMOTE HANDLE STRAIGHT
34 2
9330000018
15mm HOSE CLAMP BLOCK
35 1
9330000016
15mm HOSE GUIDE PLATE
36 1
9001194411
PIPE - FLOW CONTROL TO REMOTE BANK (EX)
37 1
9001194412
PIPE - PUMP SELECTOR TO FLOW CONTROL (FP)
38 2 9317565555 TEE F/M/M 9/16" JIC x 9/16" JIC x 9/16" JIC
39 2
9316477502
NIPPLE M/M 1/2" BSPP x 7/8" JIC ENC/SEAL
9316477501
has been superceded
REPLACEMENT SEAL =
9330006042
40 1
9316754701
NIPPLE 1/2" BSPP x 7/8" BULKHEAD ENC/SEAL
9316754700
has been superceded
REPLACEMENT SEAL =
9330006042
41 1
9001194440
1/4” HYD-HOSE RH RAM BOTTOM TO CONTROL
BANK TOP
42 1
9001194441
1/4” HYD-HOSE RH RAM TOP TO CONTROL
BANK BOTTOM
43 1
9001194442
1/4” HYD-HOSE LH RAM BOTTOM TO CONTROL
BANK TOP
44 1
9001194443
1/4” HYD-HOSE LH RAM TOP TO CONTROL
BANK BOTTOM
45 1
9001194448
1/4” HYD-HOSE CROWD RAM BOTTOM TO
FRONT FITTING
46 1
9001194449
1/4” HYD-HOSE CROWD RAM TOP TO REAR
FITTING
47 1
9001194450
1/2” HYD-HOSE 1/2” FEMALE QUICK RELEASE
TO FITTING
48 1
9001194451
1/2” HYD-HOSE 1/2” MALE QUICK RELEASE TO
REAR FITTING
49 1
9001194452
1/4” HYD-HOSE 3/8” FEMALE QUICK RELEASE
TO FRONT FITTING
50 1
9001194453
1/4” HYD-HOSE 3/8” MALE QUICK RELEASE TO
REAR FITTING
51 1
9001194462
3/8” HYD-HOSE REAR PUMP TO REAR
SELECTOR VALVE (DIESEL)
51 1
9001194466
3/8” HYD-HOSE REAR PUMP TO REAR
SELECTOR VALVE (PETROL)
52 1
9001194463
1/2” HYD-HOSE FRONT PUMP TO FRONT
SELECTOR VALVE (DIESEL)
52 1
9001194469
1/2” HYD-HOSE FRONT PUMP TO FRONT
SELECTOR VALVE (PETROL)
