Wacker Neuson DINGO K9-4 - Page 65

K94 Perkins Engine Assembly Part Numbers &
Descriptions
Item Qty Part No. Description Notes
1 1 OBSOLETE FRONT ENGINE MOUNT - ENGINE BRACKET Was 9001194807
2 1 OBSOLETE FRONT ENGINE MOUNT ASSEMBLY Was 9001194805
3 4
9518000004
RUBBER MOUNT
4 1
9519000000
PERKINS DIESEL ENGINE
5 1
9519000032
START MOTOR
AFTERMARKET =
9519100032
6 1
9330002007
HYDRAULIC PUMP 11.2/4CC
7 1
9330005020
PERKINS BELL HOUSING
8 1
9330005019
MOTOR DRIVE PLATE
9 1
9330005018
SPLINE DRIVE COUPLING GEAR
10 1
9330002008
KIT: WOODRUFF KEY, SPRING WASHER & NUT
11 1 9001194811 AIR CLEANER BRACKET PERKINS
12 1
9519000021
PERKINS FAN BELT
13 1
9519000018
WATER PUMP
1
9519000020
GASKET - WATER PUMP
14 1
9518000082
FAN
15 1 9001194821 THROTTLE CABLE BRACKET PERKINS
16 1
9519000008
PERKINS SHORT OIL FILTER
AFTERMARKET =
9519100008
17 1
9519000082
OIL FILLER CAP
1
9519000081
O-RING - OIL FILLER CAP
18 2 OBSOLETE PERKINS REAR ENGINE MOUNT Was 9001194802
19 1
9001194816
PERKINS BOTTOM RADIATOR HOSE PIPE TO
MOTOR
20 1 OBSOLETE BOTTOM RADIATOR PIPE Was 9001194814
21 1
9519000072
FUEL FILTER ASSEMBLY
22 1
9519000010
FUEL FILTER ELEMENT
1
9519100008
BOWL - FUEL FILTER
23 1
9515000036
AIR CLEANER ASSEMBLY
24 1
9515000045
AIR CLEANER RING ASSEMBLY
25 1
9515000034
INNER ELEMENT - AIR CLEANER
26 1
9515000033
OUTER ELEMENT - AIR CLEANER
27 1
9515000035
END CAP - AIR CLEANER
2
9515000015
CLIP – AIR CLEANER END CAP
1
9515000038
DUST EJECTOR – AIR CLEANER END CAP
28 1
9001194817
AIR CLEANER PIPE FROM AIR CLEANER TO
MOTOR PERKINS
29 1 OBSOLETE PUMP COVER
Was
9043300005
30 1 9001194847 RADIATOR SUPPORT ASSEMBLY PERKINS
31 1
9519000002
RADIATOR PERKINS
1
9518000181
COOLANT BOTTLE RADIATOR RECOVERY
1
9518000182
KIT RADIATOR COOLANT RECOVERY
CONTAINS
9518000181
32 1
9518000020
RADIATOR CAP
33 1 9001194347 SPLIT FAN SHROUD TOP HALF
34 1 9001194348 SPLIT FAN SHROUD BOTTOM HALF
35 1 OBSOLETE MUFFLER BRACKET PERKINS Was 9001194844
36 1
9001194819
TOP RADIATOR HOSE PERKINS
37 1
9518000050
BOTTOM RADIATOR HOSE RADIATOR TO PIPE
PERKINS
38 1
9519000006
MUFFLER PERKINS
39 1
9519000035
EXH GASKET PERKINS
40 1
9001194336
PRECLEANER TUBE
41 1
9515000048
PRECLEANER CLAMP 2 3/8" EXHAUST CLAMP
42 1 OBSOLETE TURBO PRECLEANER
Was
9515000047
43 1 9001193339 PRECLEANER BRACKET PERKINS
44 1
9515000055
PRECLEANER HOSE 190mm
45 1
9315477501
ELBOW M/M 1/2” BSPP x 7/8” JIC
REPLACEMENT O-RING =
9330006015
46 1
9319381800
HOSE TAIL 1" BSPT MALE x 1" 90°
REPLACEMENT O-RING =
9330006054
47 1
9315476501
ELBOW M/M 1/2" BSPP x 3/4" JIC 90°
REPLACEMENT O-RING =
9330006015
DINGO K94 - SERIES I, II, III
Revision 1.3 September 2020
Page 65
