Wacker Neuson DINGO K9-4 - Page 66

Item Qty Part No. Description Notes
48 3
9100000063
HOSE CLAMP 2 1/4"
49 1
9100000064
HOSE CLAMP 2 3/4"
50 2
9100000062
HOSE CLAMP 21-38mm
51 4
9100000066
HOSE CLAMP 21-44mm
52 1
9519000014
THERMOSTAT
53 1
9519000015
GASKET - THERMOSTAT HOUSING
54 2
9518000053
THREADED FRONT RUBBER MOUNT
55 2
9131231002
M10 FLAT WIDE WASHER
56 2
9111411055
HEX BOLT M10 x 55mm
57 1 9001194826 THROTTLE CABLE EXTENSION LINK
58 1 9001194346 RADIATOR OVERFLOW HOSE
59 1
9100000043
SMALL HOSE CLAMP
62 6 9113222012 SOCKET HEAD CAP SCREW 5/16" UNC x 3/4"
63 4
9113222016
SOCKET HEAD CAP SCREW 5/16" UNC x 1"
64 4
9518000032
STUD M10 x 50mm
65 4
9121142000
HEX NUT M10
66 4
9122141000
NYLOC NUT M10
70 4
9519000017
EXHAUST STUD M8 x 30mm
71 4
9120121000
M6 SPEED NUT
72 2
9120122000
M8 SPEED NUT
74 4
9120131002
HEX FLANGE NUT M8
75 2 9100000054 HOSE CLAMP 11-18mm
76 1 9340000002 3/8" OIL HOSE
77 1
9001194462
3/8" HYD-HOSE REAR PUMP TO REAR
SELECTOR VALVE
78 1
9001194463
1/2" HYD-HOSE FRONT PUMP TO FRONT
SELECTOR VALVE
79 2
9001194464
1" HYD-HOSE SUCTION 535mm
80 2
9300000006
HOSE CLAMP 34mm SUPRA
81 1
9519000042
DYNAMO
82 1 OBSOLETE
SEE NOTES
BANJO BOLT 12mm
UPGRADE REQUIRED =
9316006502
x 1
FITTING &
9001194890
x 1 HOSE
ASSEMBLY
Was 9001194845
83 2
OBSOLETE
SEE NOTES
BRASS WASHER
REFER ITEM 82 NOTES
Was 9131155000
84 1 OBSOLETE
SEE NOTES
BANJO 12mm x 3/8" HOSE 6A-2 PERKINS SUMP REFER ITEM 82 NOTES
Was 9101000002
85 1
9312650000
PLUG 3/4"X 16 TPI ADAPTOR JIC MALE
86 1 OBSOLETE
SEE NOTES
HOSE TAIL 3/8" TO 3/4" JIC REFER ITEM 82 NOTES
Was 9319166301
1
9001194890
OIL DRAIN HOSE ASSEMBLY
1
9312650000
PLUG 3/4” x 16 TPI ADAPTOR JIC MALE
1
9319366400
HOSE TAIL 3/4” JIC FM 90° x 1/2”
1
9319160400
HOSE TAIL 3/4” JIC/SAE FEM x 1/2”
.6
9345400000
HOSE 1/2” PREMOFLEX
