7 Maintenance DPU 100-70Les
38 Operator's manual
Topping up with engine oil
1. Fold up cover.
2. Remove dirt around the oil cap.
3. Unscrew and remove oil filler cap.
4. Keep pouring engine oil into the opening until the upper mark is reached on
the oil level dipstick.
See the chapter Technical data for the oil specification.
5. Screw in cover for oil filler cap, and tighten until hand-tight.
6. Wipe off any spilled oil.
Item Designation
1Oil cap
