DPU 100-70Les 7 Maintenance
Operator's manual 43
7.2.5 Checking hydraulic oil level and refilling hydraulic oil
1. Place the machine upright on a flat surface.
2. Switch off the engine.
3. Let the machine cool off.
4. Remove any dirt around the screw plug.
5. Unscrew screw plug complete with sealing ring and remove the same.
WARNING
Hot hydraulic oil.
Injury by scalding.
f Do not open the screw plug on the oil filler neck as long as the hydraulic oil
is hot.
f Let machine cool off.
Item Designation
1 Screw plug
2 Gasket
