RD 16 Operation
wc_tx001075gb.fm 31
See Graphic: wc_gr004113
Ref. Description Ref. Description
46 Turn signal switch—LEFT and RIGHT
(RD 16IRH only)
56 Low fuel indicator
47 Hour meter 57 Air filter indicator
48 Engine coolant temperature indicator 58 Glow plug indicator
49 Low oil pressure indicator 59 Parking brake ON indicator
50 Vibration ON indicator 60 Battery indicator
51 Hazard lights switch—ON and OFF 61 Water spray switch—ON and OFF
52 Lights switch—multi-position
(RD 16IRH only)
62 Water spray dial
53 Turn signal indicator
(RD 16IRH only)
63 Vibration switch —BOTH DRUMS
and FRONT DRUM ONLY
54 Throttle switch—HIGH and LOW 64 Horn
55 Ignition switch - ---
