RD 16 Maintenance
wc_tx001076gb.fm 65
ROPS parts list
Ref. Part No. Qty. Description Measurement
224 0163264 1 ROPS frame
533 0162980 2 Red reflector
550 0163627 1 Bracket
551 0163224 1 Mount
552 0162959 1 Beacon group option
594 0162345 1 Light bulb
595 0162341 1 Retaining clip
675 0020378 8 Hex head screw
699 0163948 2 Hexagonal flange head screw
733 0031565 8 Lock washer
1090 0172013 2 Pivot screw
1091 0172014 2 Pivot nut
1092 0172015 2 Washer
1093 0172016 2 Pin
1094 0172017 2 Cable
1095 0172018 2 Shockmount
1096 0172019 2 Nut
1097 0172020 1 Label
