Seat assembly parts list
Ref. Part No. Qty. Description
Measurement
and torque
1 0163274 1 Plate
2 0163324 1 Adjustable seat
3 0164779 1 Seat switch
4 0083220 1 Holder
5 0030066 4 Lock nut M8
34 Nm / 25 ft.lbs
6 0013002 2 Hex head screw M12 x 25
86 Nm / 63 ft.lbs
7 0010620 2 Flat washer B13
8 0010366 2 Lock nut M12
83 Nm / 61 ft.lbs
9 0164846 1 Hardware set
