14 Technical data
38 100_0202_td_0024.fm
14 Technical data
14.1 VP1135
Designation Unit VP1135A VP1135A US VP1135Aw VP1135Aw US
Item number 5100029066 5100029064 5100029065 5100029063
Centrifugal force kN 11.0
Oscillations Hz 98
rpm 5,880
Compaction performance* m
2
/h 533
Travel speed m/min 25,0
Gradeability % 36.4
Length (center pole in
working position)
mm 958
Width mm 355
Height mm 918
Operating weight kg 61 69
Ground clearance mm 467 566
Rated power** kW 2.6
Nominal speed rpm 3,600
Storage temperature range °C -15 – +40
Operating temperature range °C -15 – +45
Sound pressure level
At location of operation L
pA
dB(A) 93
Standard EN 500-4
Sound power level L
wa
measured
guaranteed
dB(A)
104
105
Standard EN 500-4
Vibration total value a
hv
m/s
2
4.7 4.5
Standard EN 500-4
Uncertainty of measurement
of the vibration total value a
hv
m/s
2
0.5
*
Depending on the soil properties.
**
Corresponds to the net installed power according to directive 2000/14/EC.
