14 Technical data
40 100_0202_td_0024.fm
14.3 VP1550
Designation Unit VP1550A VP1550A US VP1550Aw VP1550Aw US
Item number 5100029057 5100029055 5100029056 5100029054
Centrifugal force kN 15.0
Oscillations Hz 98
rpm 5,880
Compaction performance* m
2
/h 750
Travel speed m/min 25,0
Gradeability % 36.4
Length (center pole in
working position)
mm 1,035
Width mm 503
Height mm 940
Operating weight kg 93 102
Ground clearance mm 552 583
Rated power** kW 3.6
Nominal speed rpm 3,600
Exciter oil volume l 0.25
Exciter oil type 75W-90 API GL-4
Storage temperature range °C -15 – +40
Operating temperature range °C -15 – +40
Sound pressure level
At location of operation L
pA
dB(A) 94
Standard EN 500-4
Sound power level L
wa
measured
guaranteed
dB(A)
107
108
Standard EN 500-4
Vibration total value a
hv
m/s
2
3.1 2.7
Standard EN 500-4
Uncertainty of measurement
of the vibration total value a
hv
m/s
2
0.5
*
Depending on the soil properties.
**
Corresponds to the net installed power according to directive 2000/14/EC.
