14 Technical data
42 100_0202_td_0024.fm
14.5 Combustion engine
Designation Unit VP1135 VP1340, VP1550, VP2050
Manufacturer Honda
Type of engine GX120-UT3-QX-W2-SD,
GX120-UT2-QX-W2-SD
GX160-UT2-QW-X2-SD
Combustion method Four-cycle Four-cycle
Cooling Air cooling Air cooling
Cylinders 1 1
Displacement cm³ 118 163
Max. slanting position ° 20 20
Fuel type Gasoline Gasoline
Fuel consumption l/h 1.0 0.8
Tank capacity l 2.5 3.6
Oil specification SAE 10W-30 SAE 10W-30
Max. oil filling l 0.6 0.6
Max. performance kW 2.6 3.6
Speed rpm 3,600 3,600
Standard SAE J1349 SAE J1349
Spark plug model NGK BP-6 ES NGK BP-6 ES
Spark plug air gap mm 0.7 - 0.8 0.7 - 0.8
Starter type Recoil starter Recoil starter
