52
PXM
12345
P_02676
OPERATING AND ASSEMBLY MANUAL
VERSION 08/2015 ORDER NUMBER DOC2350372
7.6.1 PAINT CHANGE COMPONENTS
1 Blowout nozzles for intake tubes
2 Blowout nozzle for the fresh powder hose and peristaltic pump tube
3 Parking station peristaltic pump tube during loss operation
4 Parking station, fresh powder hose
5 Cleaning position, fresh powder lance
