111
PXM
6
5
P_02693
7
OPERATING AND ASSEMBLY MANUAL
VERSION 08/2015 ORDER NUMBER DOC2350372
15.5 CYLINDER WORKSTATION 34 INJECTORS
Pos K Quantity Order No. Designation
5 1 2359655 Pneumatic cylinder 80 x 525
6 2 2354879 Guide bush
7 4 2309763 Proximity switch with holder
Wearing part
