WAGNER EvoMotion 5-125 - Operating Elements; Pressure Regulator Unit

24
VERSION 01/2018
ORDER NUMBER DOC 2316596
5.6 OPERATING ELEMENTS
5.6.1 PRESSURE REGULATOR UNIT
B_06876
geschlossen





Designation
1 Ball valve Open: working position
Closed: The air motor may still be under pressure.
2 Safety valve
3 Pressure regulator
4 Pressure gauge (air inlet pressure)
5 Compressed air inlet
