49
VERSION 01/2018
ORDER NUMBER DOC 2316596
Order no. Designation
1 1 U3B08018060A Air motor M80 EM C60
2 1 F132.91C Motor ange, upper, M80 EM
3 2 L108.06 O-ring
4 1 D608.81 Cylinder motor
5 1 3055157 Hexagon nut with clamp
6 1 9992757 Threaded elbow tting
7 2 G903.06 Damper
8 1 L413.06 Seal DE 80
9 1 A164.01 Motor piston
10 1 L802.08 Sliding ring
11 1 L110.06 O-ring
12 1 D404.12 Piston rod, M80 EM
13 2 L109.06 O-ring
14 1 A408.12 Air tube, M80 EM
15 1 T616.00C Motor ange, complete M80 EM, at bottom
16 1 P498.00KNE Reversing valve ISO N/1
17 1 367258 Grounding, complete
18 1 L403.06 Rod seal
19 1 T703.00 Sensor below, M80
20 1 K606.02 Lock washer for waves
21 1 A160.01A Washer
22 1 369290 Pilot valve
23 2 H505.07 Silencer
24 1 9920106 Washer
25 1 M432.00 Reducing nipple
26 2 9992265 Angled threaded tting
27 1 9992831 Loctite 542
28 4 9907241 Hexagon socket cylinder head screw
29 1 9998808 Mobilux EP 2 grease
30 1 9998157 Loctite 480
31 1 G735.06AB Valve sealing
32 1 A818.71B Valve plate
33 4 9920104 Washer
34 4 9900386 Hexagon socket cylinder head screw
35 1 P498.00 Reversing valve P/1 SP/NUM (spare parts, see Chapter 8.3.1)
1 T910.00 Service set, air motor EM 30-30/ 40-15/ 5-125
= Wearing parts
= Included in service set
