51
VERSION 01/2018
ORDER NUMBER DOC 2316596
Order no. Designation
1 U2B125FC Fluid section 125 St PE/T
2 1 F142.21 Spacer MP
3 1 L136.06 O-ring
4 1 T971.00E Packing PE/T 36/50
5 1 H212.03 Spring, upper
6 1 A645.01 Washer
7 1 A644.12 Cylinder ange
8 4 9907079 Hexagon socket cylinder head screw
9 1 D114.42A Pump rod D36
10 2 G609.08 Seal
11 1 A646.03 Piston valve
12 1 B0344.03 Special screw M6x35
13 1 K311.03A Self-locking hexagon nut
14 1 K108.03 Hexagon socket cylinder head screw
15 1 A827.03 Rod coupling
16 1 D710.22 Pump cylinder
17 1 A647.03 Pump rod
18 1 A648.03 Rod bush
19 1 A649.03 Piston valve
20 1 9913031 Self-locking hexagon nut
21 2 K317.03 Hexagon nut
22 1 A179.03 Valve foot
23 1 L137.06 O-ring
24 1 A650.03 Inlet housing
25 1 K604.22 Securing ring
26 1 A651.03 Valve stop
27 1 K158.03 Hexagon socket cylinder head screw
28 1 A253.01 Support ring
29 1 A250.01 Support ring
30 3 G121.05 Sealing collar T 36/50
31 3 G121.08E Sealing collar PE 36/50
32 1 9992831 Loctite 542
33 1 9998808 Mobilux EP 2 grease
1 T958.00AE Service set - EvoMotion uid section 125 cm³
= Wearing part
= Included in service set.
