WAGNER EvoMotion 5-125 - Page 24

Operating manual Piston Pump EvoMotion 5-125
5 Description
24 Order number 2316596 | Edition 03/2021
EvoMotion 5-125
0
30 (3)
<440>
20 (2)
<290>
10 (1)
<150>
0
10 20 30 40 50 60
240
<8>
160
<6>
80
<3>
0
7.50
<1.98>
6.25
<1.65>
5.00
<1.32>
3.75
<0.99>
2.50
<0.66>
1.25
<0.33>
0
A
B
C
bar (MPa)
<psi>
nl/min
<scfm>
l/min
<gpm>
A
B
C
40 (4)
<580>
320
<11>
B_07820
1
3
4
2
1 Product pressure in bar; (MPa); <psi> A Characteristic curve for air pressure 8
bar; 0.8 MPa; 116 psi
2 Stroke frequency in DH/min. -- --
3 Air consumption in nl/min.; <scfm> B Characteristic curve for air pressure 6
bar; 0.6 MPa; 87 psi
4 Flow rate of water in l/min.; <gpm> C Characteristic curve for air pressure 4
bar; 0.4 MPa; 58 psi
