28
GM 5000EA
OPERATING MANUAL
EDITION 07/2014
ORDER NUMBER DOC
2344499
6.4.2 VENTILATION OF THE SPRAY BOOTH
The GM 5000 EA spray gun must be combined with various components to make up a
spraying system (spray pack). The system shown in gure B_03233 is only one example
of an electrostatic air spraying system. Your Wagner distributor would be happy to assist
you in creating a spraying system solution that meets your individual needs. You must
familiarize yourself with the operating instructions and the safety regulations of all
additional system components before starting commissioning.
The electrostatic hand spraying equipment is for use only in spray areas which correspond
with standard EN 12215.
The electrostatic hand spraying equipment has to be locked to the technical ventilation
so that the coating product supply and the high-voltage are not e ective as long as the
technical ventilation is not operated with the minimum exhaust air volume ow or a larger
exhaust air volume ow.
Ensure that the excess coating product (overspray) will be collected up safely.
Incorrect installation/operation!
Risk of injury and equipment damage.
When putting into commissioning and for all work, read and
follow the operating manual and safety regulations for the
additionally required system components.
WARNING
Toxic and/or ammable vapor mixtures!
Risk of poisoning and burns.
Operate the device in a spray booth approved for the working
products.
-or-
Operate the device on an appropriate spraying wall with the
ventilation (extraction) switched on.
Observe national and local regulations for the outgoing air
speed.
WARNING
