32 ProSpray 24
g
Description of unit
1 Pail hook
2 Suction tube
3
Filter
4 Return hose
3.5 Legend for explanatory diagram of upright cart unit
4
1
2
3
3.6 Explanatory diagram of upright cart unit
P
arts not identified are the same as on
Figure 3.
