Super Finish 21 • 23 45
gg
Accessories and spare parts
12.11 Spare parts list pump aggregate Super Finish 21 and 23 (spare parts diagram, see page 99)
Super Finish 21 Super Finish 2
3
Item Order no. Order no. Description
Super Finish 21 Super Finish 2
3
Item Order no. Order no. Description
1 0344 205 0344 205 Housing
2 9905 111 9905 111 Oval head screw 5 x 20 (9)
3 9905 112 ––––––– Screw M 6 x 20 (4)
––––––– 9905 112 Screw M 6 x 20 (2)
4 9950 241 9950 241 Socket
5 9950 242 9950 242 Seal
8 0340 302 0340 302 Connecting plate
9 0340 353 0340 353 Toothed belt
––––––– 0341 353 Toothed belt (220 Volt~, 60 Hz)
10 0340 352 0340 352 Toothed belt disk
––––––– 0341 352 Toothed belt disk (220 Volt~, 60 Hz)
13 0341 706 0341 706 Eccentric shaft, item 14 –> 21
14 3056 464 3056 464 Securing ring 72 x 2.5
15 9970 532 9970 532 Shaft seal 40 x 72 x 10
16 0341 324 0341 324 Eccentric shaft
17 9960 151 9960 151 Groove ball bearing 6207
18 9922 518 9922 518 Securing ring 35 x 1.5
19 9960 431 9960 431 Roller bearing NUTR 25
20 9922 506 9922 506 Securing ring 25 x 1.2
21 9960 432 9960 432 Cylinder roller bearing NJ 202
24 9900 315 9900 315 Cylinder head screw M 6 x 25 (4)
25 9920 806 9920 806 Disk 6.4 (4)
26 0344 210 0340 225 Hydraulic housing
27 9993 105 9993 105 Nipple
28 0341 445 0341 445 Return hose
29 0288 317 0288 317 O-ring 6.07 x 1.78
30 0288 309 0288 309 Angle piece
31 0341 446 0341 446 Suction hose
32 0341 307 0341 307 Seal
33 0341 309 0341 309 Cover
34 3050 858 3050 858 Disk 5.3 (6)
35 9906 007 9906 007 Cylinder head screw M 5 x 45 (6)
36 0341 348 0341 348 Oil dip-stick
37 9971 146 9971 146 O-ring 16 x 2
38 0341 349 0341 349 Oil cap screw
39 0340 490 0340 490 Hood
40 9903 317 9903 317 Screw M 4 x 12 (2)
* When exchanging these parts the operating pressure must be reset by the customer service.
41 9952 855 9952 855 Capacitor 20 MF/400 V
(230 V, 50 Hz, 220 V~, 60 Hz)
9952 859 9952 859 Capacitor 40 MF/250 V (110 V~, 50 Hz)
42 0340 351 0340 351 Toothed belt disc
43 0340 397 0340 397 Ventilator
44 0340 398 0340 398 Locking ring
45 0340 399 0340 399 Ventilator hood
46 9921 504 9921 504 Spring ring 4
47 9900 737 9900 737 Cylinder head screw M 4 x 6
48 0340 203 0340 203 Electric motor 230 V~, 50 Hz
––––––– 0340 216 Electric motor 220 V~, 60 Hz
0340 215 0340 215 Electric motor 110 V~, 50 Hz
50 0340 354 0340 354 Seal
51 0261 352 0261 352 Unit connection line
H07RN – F3G 1.5 – 6 m
52 9951 074 9951 074 Cable screw connection
53 9951 075 9951 075 Nut
54 9951 878 9951 878 Control lamp
9951 879 9951 879 Control lamp (110 V~, 50 Hz)
55 9953 696 9953 696 ON/OFF switch
9953 681 9953 681 ON/OFF switch (110 V~, 50 Hz)
58 9971 365 9971 365 O-ring 9.25 x 1.78
59 0340 222* 0340 222* Regulating unit
60 0010 861* 0010 861* Pressure spring
61 0010 858* 0010 858* Clamp
62 0010 859* 0010 859* Stop sleeve
63 0158 251* 0158 251* Pressure regulating knob
64 0340 223* 0340 223* Pressure regulating valve
65 9900 524 9900 524 Countersunk screw 2.9 x 6.5 (2)
66 0344 332 0344 332 Nameplate
without diagram
9984 510 9984 510 High-pressure hose DN 4 mm,
7.5 m with stainless steel nipple
9984 507 9984 507 High-pressure hose DN 6 mm,
15 m for dispersion
9984 562 9984 562 High-pressure hose DN 6 mm,
30 m for dispersion
