ø 10mm
(ø ") 3/8
7
Step 3.1
Select TV Screws
Step 2.2
Step 3
Mark the position of the hole on your mounting surface. Drill a 3/8"(10mm) diameter hole at the marked position through the
mounting surface. Insert the assembled Bolt I through the desk hole, guide the Support Plate J and Nut H through the Bolt I ,
rotate the Nut H to fasten for stability.
2b Self-drilled Grommet Hole Installation
I
J
H
0.4”-3.3”
