Wali GSWM002 - Wall Mounting; Wood Stud Installation

3
Step 1
A
Option A
Wood Stud
X
W-A
W-C
W-A
W-C
3. Attach the mount to wood stud and tighten using Screw W-A & D5 Washer W-C with a screwdriver.
(Screwdriver not included)
1. If installing this product on wood stud, mark the position with Bubble Level & pencil
on the wall.
2. Drill 3/16"(4.5mm) diameter x 2.2”(55mm) length holes at the marked position.
Stud Finder
