Option B
Concrete Wall
2. Drill 3/8"(10mm) diameter x 2.2”(55mm) length holes at the marked position.
W-B
W-A
W-C
W-A
W-B
W-C
1. If installing this product on concrete wall, mark the position with Bubble Level &
pencil on the concrete wall.
3.
Insert the Anchor W-B into the mounting holes. Attach the mount to concrete wall and tighten using Screw W-A
& Washer
W-C with a screwdriver. (Screwdriver not included)
To Next Page
