Wali GSWM002 - Monitor Attachment and Adjustment; Cover and VESA Plate Installation

Step 2
Step 3
5
Step 3.1
Select TV Screws
Step 3.2
M-C
M-C
M-A
M-B
D
A
c
C
Fix Cover C onto the front of mount part.
Attach the VESA Plate B to your TV/Monitor, and thread M4x12 Bolt M-A or M5x12 Bolt M-B into the mounting
holes with D5 Washer
M-C , tighten with Allen Key 5mm D .
