Supplied Parts List
2
CAUTION!
WARNING
!
This monitor desktop mount must be securely
attached to the horizontal desk. If the mount is
not properly installed it may fall, resulting in
possible injury and/or damage.
(1) Pole-a (1) Swivel Arm-d(1) “C” Clamp-b
(1)Support Plate-j(1)M10 Bolt-i (1)M10 Washer-k (1)Spring Washer-l
(8)M4 Spacer-s
(8)M4x12
Thumb Bolt-q
(8)M4x30 Bolt-r
(1) “C” Clamp Brace-c
(2) VESA Plate-e (3) M5x14 Bolt-f (2) M8x12 Bolt-g (2) Nut-h
(1) Grommet Base
Plate-m
(1)Wire Clip-n1 (1)Allen Key-o
(1)Wrench-p
(4)Wire Clip-n2
