Operating Instructions
46
1. 2.
8600-44
Catcher
Door
Grass Catcher
Lift Channel
RH Catcher
Door Arm
LH Catcher
Door Arm
Cable
Assembly
Door Arm
Actuator
Cable
Guide
Catcher Door
Gas Spring
Power Dump
Mount
Lift
Arm
Gas
Spring
Power Dump
Ram Actuator
Guard
Power Dump
Switch
Power Dump Components
