67
Maintenance Instructions REPLACING/REPAIRING
REPLACING/REPAIRING
DANGER
To prevent accidental starting of the en-
gine when replacing parts or repairing the
machine, remove the key from the ignition
switch and disconnect the spark plug
wires.
IMPORTANT: ALWAYS use genuine factory re-
placement parts. Substitute parts CAN result in
product malfunction and possible injury to the op-
erator and/or others.
Drive Belts
There are three (3) individual belts on the ma-
chine:
● Engine Belt (Matched Set of 2)
● PTO Drive Belt
● Ground Drive Belt
The belts may be removed and replaced using the
procedures described on the following pages.
Belt Locations
Engine Belt
(Matched Set of 2)
PTO Drive Belt
Ground Drive Belt
To Next Page
