CHAPTER 7 THE MODE-MENU
SENSOR is OFF (menu point 7). For this determination the LIGHT-
SENSOR must be fixed instead of the sample in front of the
fiberoptics. When the routine is carried out, the LIGHT
AVERAGING function (menu point 6) is disabled. If it is afterwards
required, it must be manually enabled. After the LIGHT-
CALIBRATION the EXT.LIGHT-SENSOR (menu point 7) is in the
OFF-position.
When in ON-position, the DISPLAY is
continuously illuminated. It should be
noted, that this may cause considerable costs of battery power. When
in OFF-position, DISPLAY ILLUMINATION can be transiently
turned on for 40 s by pressing ON for 3 s.
9: DISP.ILLUM:OFF(SET)
F: 448 745Y 6.2E 20L
On/off switch to enable/disable the power
saving automatics which turn off the
MINI-PAM after 4 min without key operation. It is advisable to
disable the AUTO-OFF when the MINI-PAM is connected to an
external power supply (via CHARGE-socket). Whenever the
instrument is switched off manually, the AUTO-OFF function is
enabled again (automatic reset to ON-position). The AUTO-OFF
function is also automatically enabled when battery voltage drops
below 11.2 V.
10: AUTO-OFF: ON (SET)
F: 448 745Y 6.2E 20L
Function to average a number of
consecutive YIELD- and ETR-deter-
minations. The SET-key is used to reset the counter to 0 and to erase
the averaged values of the preceding measurements. For safety's sake
the reset must be confirmed by pressing the ∧-key. The averaged
YIELD and ETR are shown in the top line, whereas in the bottom
line the values of the last measurement are displayed.
11:AV. 564Y 5.9E 8No
F: 448 745Y 6.2E 20L
On/off switch of the internal actinic light
source (halogen lamp). This can also be
directly operated via ON + SET. The internal actinic lamp is not
12: ACT-LIGHT: OFF(SET)
F: 448 745Y 6.2E 20L
19
