CHAPTER 8 COMPONENTS OF THE MINI-PAM
quanta m
-2
s
-1
at 0.6 kHz and 5 µmol quanta m
-2
s
-1
at 20 kHz. These
values are lowered to 1/5 when the burst mode is active. At such low
intensities an "actinic effect" of the measuring light normally can be
excluded.
8.1.2 Special information on MINI-PAM/B
Recently strong blue LEDs with an emission peak around 470
nm have become available and the MINI-PAM/B was developed
which employs such LED as measuring light source. Using 470 nm
measuring light has a number of technical and practical
consequences which shall be briefly outlined.
• Excitation filters:
The 470 nm LED light is passing through a set of short-pass
filters with λ < 620 nm (Balzers DT Cyan special).
• Detector filters:
The PIN-photodetector is protected by a set of long-pass filters
with λ > 650 nm (Balzers R65 and Schott RG 645).
• Measuring light:
At the same intensity setting (MEAS-INT) the integrated
intensity of the measuring light pulses of the blue version is less
than that of the red version by approximately a factor of 3.
Therefore, the MEAS-INT can be applied at higher settings
without the risk of an actinic effect.
• Actinic light:
The actinic light passes the same filters as the measuring light.
Therefore, the short-pass wavelength of 620 nm not only applies
to measuring light but to actinic light and saturation pulse light
as well. Consequently, as the red component of the halogen lamp
31
