Wascomat EX618co - Siting and Floor

23
Installation
5327
6
2"
20"
50 mm
500 mm
Siting and floor
Install the machine close to a floor drain or open
drain.
In order to make installation and servicing the
ma chine easier the following clearances are
recommended:
• Atleast20inches(500mm)betweenthe
machine and the wall behind
• andmin.2inches(50mm)onbothsidesof
the machine whether installed next to the wall
or other machines.
6
