Wascomat EX618co - Casting a Plinth

27
150-200 mm
40 mm
125
Installation
5462
0899A
11
10
Casting a plinth
A foundation should be used where the existing
floor is less than 8 inches (200 mm) thick or in
order to ensure that the machine is securely an-
chored and will not vibrate excessively.
The foundation must be at least 8 inches
(200 mm) thick.
Proceed as follows:
• Breakuptheexistingoortoadepthofap
prox.5inches(125mm)andcheckthatthe
sidesoftheholearetaperedoutwardsothat
the longest side at the bottom measures 5
inches(125mm)morethanatthetop.
• Maketheformsforthefoundation.
• Moistentheholewellandapplycementtothe
sides and bottom.
• Anumberofmountingboltsmustbeset
into the concrete of the foundation.
Theboltsneedtoproject111/2inches(40
mm) out of the base. Pour the con crete into
thepreparedbasemoldandmakesurethat
the surface is level.
• Theconcreteshouldbelefttosetforatleast
two days before mounting the machine on the
foundation.
• Mountingboltlocationsareshownwith
respecttotheoutersurfaceofthemachin's
frontpanel.Ifthefrontpanelistobesetback
from the front of the foundation, add the set-
back distance to dimension "E".
