Wascomat EX618co - Connection of External Liquid Supplies

33
Installation
A
B
1
2
3
4
1
2
3
4
5
7
6
9
23
6598
6572
24
Connection of external liquid supplies
The external dosing equipment power
supply must never be connected to the
machine’s incoming terminal block or to
the edge connectors on the IO-board.
Machines fitted with connectors
• Connectthepumpequipmenttoconnections
AandBonthewashingmachine.
ConnectthesignalcabletoBandthepower
supplytoA.
Machineswithoutconnectors
• Connecttheexternalpumpequipmentfor
liquidwashingdetergenttotheI/Oboard,
whichislocatedtotherightoftheincoming
powersupply.
TheI/Ocardhasedgeconnectorsforconnec-
tingexternalpumps.
• EdgeconnectorsontheI/Oboardcanbe
loosenedforconnectingcables.
23
24
1 = N
2 = L
4=Ground
1 = N
2=Programrun
3=Signal1
4=Signal2
5=Signal3
6=Signal4
7=Signal5
11 = N
18=Programrun
12=Signal1
13=Signal2
14=Signal3
15=Signal4
16=Signal5
