Wasp CCD Scanner User Manual

Chapter 5
13
TERMINATOR/CODE ID
12
O - MSI/Plessey T - EAN 128
S - EAN 8 K - Code 128
E - UPC E N - Codabar
A - UPC A D - Full ASCII Code 39
F - EAN 13 M - Std. Code 39
L - Code 93 I - Interleaved 2 of 5
Terminator
CR *
N o n e
Code ID
Code ID On
Code ID Off *
L F
CR + LF
Ta b
S p a c e
E S C
The ‘Terminator’ option is used to specify the end-of-text message and is
primarily used to denote the end of the barcode value.
The ‘Code ID’ option sends a specific value when a particular barcode
symbology is scanned. For example, if ‘Code ID’ is enabled and Code 39
is scanned, an “M” will appear in the data stream in front of the
barcode value.
*Default
WCS3900_3905Manual0707_sm.A0 6/25/08 4:32 PM Page 13
