Wasp CCD Scanner - Chapter 3 Installation; WCS3900 USB Scanner Installation; WCS3900 PS2 Scanner Installation

Chapter 3
4
Installation
Trigger
Trigger
Scanning Aperture
Scanning Aperture
Din-6M
Din-6F
USB Port
1. Insert the USB cable directly into your PC’s USB port.
1. Turn off your computer.
2. Unplug your PC keyboard cable and plug the male end (Din 6)
of the WCS3900 Scanner directly into your PC keyboard port.
Plug your keyboard cable into the other end (female Din 6) of the
the scanner.
3. Turn your computer on.
WCS3900 PS2 Scanner
WCS3900 USB Scanner
