Chapter 5
17
INTERLEAVED 2 OF 5 AND CODE 93 SETTINGS
16
Enable Code 93 Disable Code 93 *
Enable Interleaved
2 of 5 *
Check Digit Do
Not Calculate *
Check Digit Calculate
But Do Not Send
Minimum Length (6 *) Maximum Length (48 *)
Disable Interleaved
2 of 5
Check Digit Calculate
And Send
Interleaved 2 of 5 is a variable length, even numbered, numeric barcode.
It is typically used in industrial and master carton labeling and also in the
automobile industry. The symbology uses bars to represent the first digit
of a pair and the interleaved (white) spaces to represent the second digit
of a character pair.
See page 6 for information on setting the minimum and maximum lengths.
Code 93 encodes the full 128 ASCII character set using 9 modules
arranged into 3 bars with adjacent spaces. Two of the characters are
check characters. Code 93 is similar to Code 39 but encodes more
characters per inch.
Minimum Length (6 *) Maximum Length (48 *)
*Default
WCS3900_3905Manual0707_sm.A0 6/25/08 4:32 PM Page 17
