Electrochlor Mineral Chlorinator
To select the type of pump, rotate the wheel to pump type and press it,
then select the type of pump.
• Selecting variable speed pumps: rotate the wheel to variable speed and
press wheel to confirm selection.
• Controlling a secondary pump: once the selection of variable speed
pump has been confirmed, rotate the wheel to select AUX1 and set it to
Independent Pump. This enable the pool pump GPO as AUX1 and can
be used as secondary pump.
Note: The control of the variable speed pump is executed via communication
cable. When the pump is controlled via the communication cable the pump can
be connected to an independent power output. This enables the pump GPO
to be used as an independent output to control a secondary pump (booster
pump) or any other equipment that needs to be operated at the same time of
the pool pump. This also can be used to interlock functions. Please refer to the
Interlock section below for more information.
Only one pump can be plug to the Electrochlor GPO or else the
combined amperage will exceed the chlorinator's maximum. The only
way to operate two pumps is for a variable speed pump to be plugged
into a separate GPO.
Warning
