Electrochlor Mineral Chlorinator
8. TROUBLESHOOTING GUIDE
Symptom Remedy
Low chlorine level in pool
Operating time too short. Increase operating time.
Production control set too low. Set production higher.
Low salt. Add required amount of salt.
Pool chemistry not correct. Have water tested.
Unit does not operate Connect power, check fuse, switch on Electrochlor.
Not keeping time Return to distributor for repair.
Blank Screen Return to distributor for repair.
No chlorine production
Check chlorine production settings.
Set Time Switch to ON or AUTO position.
Pump does not come on:
Check timer settings, Auto Time mode.
Check Diagnostic Outputs menu for pump on. If on
then it’s not in user programming but some connection
problem.
Pump on but no cell activity:
Wait 30 seconds.
Check Cl setting, cable correctly plugged in, salt level too
high and unit is cycling on low settings. Increase setting.
Check Diagnostic Outputs menu if Cell on and Flow is on.
If on then it’s not user programming but some connection
or cell drive problem.
Wrong activation on timer: Check wrong mode selected Winter/Summer.
Light does not work:
Is Light Icon is on? See light operation. In Timer mode,
check light is ticked in operation box. Check Diagnostic
Outputs menu.
Light flashes on basic light
when powered up:
Is Light Icon is on? See light operation. In Timer mode,
check light is ticked in operation box. Check Diagnostic
Outputs menu.
Light flashes on basic light
when powered up:
Wrong type selection in settings.
Light wrong colour after
changing colour:
Sync cycle interrupted, wait time after sync flashing
interrupted.
Light is different colour than
last activation upon
re-activation or changes
colour by itself:
Intermittent connection to light power.
Valve does not change over:
Wait for time delays to finish. Check Diagnostic Output
menu.
Temperature display is wrong:
Go to calibration screen and action if necessary; check
probe is plugged in.
