Electrochlor Mineral Chlorinator
I. Default Settings
Default Mode: Auto
Default Timer Setting: On from 08:00 to 12:00
And from 16:00 to 20:00
Temperature: set in Celsius Degree
Pump Type: Single Speed
Chlorine Production: 100%
Light: Single Colour Light
Display Auxiliary: Off
Minimum Chlorine: N.O.
InterLock/InterLink Function
InterLock: The interlock feature ensures that the filtration pump is operating prior to
allowing another system component to operate.
InterLink: The interlink feature allows the user to operate two or more functions
together. Select the “Interlink” button and then select the function required to operate
with the relevant output.
The Pump Output (Auxiliary 2) can be made available for a secondary pump. This will
only be possible, when a variable speed pump is connected to an external and suitable
GPO/output.
This feature is only available when a VSD pump is in use and connected to Electrochlor
via a communication cable.
Functionality:
• If any function that is interlocked to the filtration pump is activated, the filtration
pump will switch on. Electrochlor will check all interlocked functions, set the
minimum required pump speed required by any interlocked function.
• If any interlocked output is manually switch on, the filtration pump will switch to the
preset pump default speed.
• If the filtration pump is manually turned off all interlocked function will also turn off.
• If an interlocked function is turned off outside a filtration time the filtration pump
will turn off.
• If any function that is interlocked is manually turned on/off or automatically turned
on/off the pump speed is checked and set to minimum required by the running
function.
• If an interlocked function is turned off within a timer cycle if no other functions are
operating the filtration will lower is pump speed to the default pump speed.
• “Pump Speed limited” will be displayed if user tries to select a pump speed that is
below the required speed of an interlocked function.
• When filtration pump is deactivated, it will also deactivate all interlocked outputs.
• If the user selects a lower pump speed (below activation speed) the interlock
functions cease.
