Preparing the mass spectrometer for operation with the APGC 2-7
6. Insert the collar into the sample cone.
Inserting the collar into the sample cone:
7. Rotate and lift the tool and collar to remove the sample cone from the
cone gas nozzle.
Tip: Store the cone gas nozzle in a safe location.
Removing the sample cone:
Caution: To avoid damaging the fragile sample cone, do not place
it on its tip; instead, place it on its flanged base.
Sample cone
Cone gas nozzle
