Watlow Series SD 23 Chapter 3 Keys and Displays
Setup Page (continued)
[Ot`2] Output 2 Function
[Ctr2] Control Method 2
[Ftb2] Fixed Time Base 2
[PL`2] Power Limit 2
[PSL2] Output Power Scale Low 2
[PSh2] Output Power Scale High 2
[nLF2] Output Non-linear Function 2
[[Ot`3] Output 3 Function
[Ctr3] Control Method 3
[Ftb3] Fixed Time Base 3
[PL`3] Power Limit 3
[PSL3] Output Power Scale Low 3
[PSh3] Output Power Scale High 3
[nLF3] Output Non-linear Function 3
[AO3;U] Analog Output 3 Units
[O3;Lo] Analog Output 3 Low Scale
[O3;hi] Analog Output 3 High Scale
[r3;So] Output 3 Retransmit Source
[r3;Lo] Output 3 Retransmit Low Scale
[r3;Hi] Output 3 Retransmit High Scale
[r3;CO] Output 3 Retransmit Offset
[hyS1] Alarm 1 Hysteresis
[Lgc1] Alarm 1 Logic
[LAt1] Alarm 1 Latching
[SiL1] Alarm 1 Silencing
[dSP1] Alarm 1 Message
[hyS2] Alarm 2 Hysteresis
[Lgc2] Alarm 2 Logic
[LAt2] Alarm 2 Latching
[SiL2] Alarm 2 Silencing
[dSP2] Alarm 2 Message
[hyS3] Alarm 3 Hysteresis
[Lgc3] Alarm 3 Logic
[LAt3] Alarm 3 Latching
[SiL3] Alarm 3 Silencing
[dSP3] Alarm 3 Message
[ACLF] AC Line Frequency
[Unit] Units of Measurement
[I;Err] Input Error Latching
[FAIL] Input Error Failure Mode
[MAn] Input Error Power
[`dSP] Active Displays
[``rP] Ramping Mode**
[rP;Sc] Ramp Scale**
[rP;rt] Ramp Rate**
[Ptyp] Profile Type***
[PStr} Profile Start***
[gs;dE] Guaranteed Soak Deviation Enable***
[`gsd] Guaranteed Soak Deviation Value***
[Addr] Modbus Device Address
[bAud] Baud Rate
[t;tun] TRU-TUNE+™ Enable****
[AgrS] Autotune Aggressiveness
[t;bnd] Tune Band****
[`t;gn] Tune Gain****
[`LOC] Lockout
Setup Page Overview
[`SEt]
[PAgE]
The Setup Page contains parameters that define
basic controller functions. Go to the Setup Page
for initial configuration or if your application re-
quirements change. Be sure to program the Setup
Page first!
Always press the Infinity Key ˆ to return to the
Home Page.
You must start from the Home Page.
To go to the Setup Page, press both the Up ¿ and
Down ¯ keys for about three seconds.
• Press the Advance Key to move through
the parameter prompts.
• Press the Up ¿ or Down ¯ keys to change
the parameter value.
Press the Infinity Key ˆ at any time to re-
turn to the Home Page.
Note: Hardware configuration and programming selec-
tions determine what parameters appear on the Setup
Page.
Note: The Setup Page is not accessible while a profile is
running.***
** Static set point version only
*** Profiling version only
**** TRU-TUNE+™ version only
Setup Page
[`Sen] Sensor Type
[`Lin] Thermocouple Linearization
[`C-F] Temperature Units
[S;deC] Temperature Decimal Places
[P;dEC] Process Decimal Places
[IS;En] InfoSense
[IS;P1] InfoSense Point 1
[IS;P2] InfoSense Point 2
[IS;P3] InfoSense Point 3
[IS;P4] InfoSense Point 4
[Sc;Lo] Process Scale Low
[Sc;hi] Process Scale High
[P1;LE] Process Input Low Error
[P1;HE] Process Input High Error
[rg;Lo] Units Scale Low
[rg;hi] Units Scale High
[SP;Lo] Set Point Low Limit
[SP;hi] Set Point High Limit
[Ftr;E] Input Filter
[FLtr] Filter Value
[Ot`1] Output 1 Function
[Ctr1] Control Method 1
[Ftb1] Fixed Time Base 1
[PL`1] Power Limit 1
[PSL1] Output Power Scale Low 1
[PSh1] Output Power Scale High 1
[nLF1] Output Non-linear Function 1
[AO1;U] Analog Output 1 Units
[O1;Lo] Analog Output 1 Scale Low
[O1;hi] Analog Output 1 Scale High
[r1;So] Output 1 Retransmit Source
[r1;Lo] Output 1 Retransmit Low Scale
[r1;Hi] Output 1 Retransmit High Scale
[r1;CO] Output 1 Retransmit Offset
